Rain Spray Environmental Test Chamber Dustproof Stainless Steel

Product Categories
Guangdong ALI Testing Equipment Co,.Ltd
Contact Now

Rain Spray Environmental Test Chamber Dustproof Stainless Steel

  • 1
  • 2

Brand Name : GSKA

Model Number : Environmental Test Chamber

Certification : CE SGS ROHS UL CE

Place of Origin : Dongguan China

MOQ : Negotiate

Price : Negotiate

Payment Terms : T/T, L/C

Supply Ability : 100 Set / Sets per Month

Delivery Time : 10-60days after confirmed payment or by contract stipulation

Packaging Details : Export package

Normal wire diameter : 50um

Box Material : SUS 304 Stainless Steel

Temperature fluctuation : ±1.0℃

Temperature uniformity : ±2.0℃

Customized support : OEM

Power : 220V , 50Hz

Condenser : Water-cooled condensing agent

Keyword : Environmental Chambers

Contact Now

Rain Spray Environmental Test Chamber Dustproof Stainless Steel

Description & Application:

Rain spray test chamber simulates the watet drip environment to test the water resistance and sealing of the samples during storage, transportation and usage. It is widely applied to electrical and electronic products, lamps and lanterns, electrical cabinet, electrical components, automobile, motorcycle and its spare parts and other products. It provides the basis to improve the performance of the products.


This product uses the scientific design makes the device capable of realistic simulation drip, water spray, splashing water, environmental, water and so on. Into the overall control system and the use of inverter technology, making the rotation angle of rainfall in the test frame, spray angle and swing the pendulum swinging spray volume can automatically adjust the frequency.

Test Area & Shelf:

●Interior of Chamber is SUS304 stainless steel.


●A stainless steel shelf for placing test specimens


●Standard load of shelf is 50kg


●Normal wire diameter is 50 um.


●Normal width of a gap between wires is 75um.


●Built-in power interface for test specimen


●Test chamber internal illumination


●Vacuum system for specimen

Performance parameters:

Internal dimensions (mm)
800*1000*1000
1000*1000*1000
1000*1500*1000
1000*2000*1000
Overall dimensions (mm)
1040*1450*1960
1200*1450*1960
1250*1900*1960
1300*2400*1960
Temperature range
Ambient to +50℃
Relative Humidity
<30%RH
Normal wire diameter
50um
Normal width of a gap between wire
75um
The Talcum powder amount
2kg ~ 4kg/m3
Fight time
0 ~ 99H59M
Fan cycle time
0 ~ 99H59M
Specimen power outlet
Dust-proof socket AC220V 16A
Controller
programmable color display touch screen controller
PC Link, R-232 interface
Vacuum system
Equipped with a pressure gauge, air filter, pressure regulator, connecting tube
Exterior material
Steel Plate with protective coating
Interior material
SUS304 stainless steel
Safety System
Electric leakage, short circuit, Over-temperature, motor overheating Over-current protection/ Power failure memory function for
controller
Power supply
380V 50HZ
Standard
IEC60529, ISO20653

Rain Spray Environmental Test Chamber Dustproof Stainless Steel


Middle service:


--Give you best offer.


--Provide discount for many sets order.


--Do customer's request.


--Choose payment term you convienent.


--Promptly production and delivery,inform you in time.

After sale service:


--14 months warranty service and all life maintenance.


--Technical Egineer are avalible for oversea trainning.


--Free change for some parts.


--Remote control technical consult.


--Free installation DVD.


--Maintenance plan.
